Back-up lamps circuit for Ford Explorer III (2001-2006)
Back-up lamps circuit
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
CENTRAL SECURITY MODULE (BEHIND TOP RIGHT SIDE OF DASH)
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (AT CENTER OF AUTOMATIC TRANSMISSION)
ELECTROCHROMATIC INSIDE MIRROR UNIT (W/ KEYLESS ENTRY)
HOT IN RUN FUSE 19
LEFT REVERSING LAMP
RIGHT REVERSING LAMP
VIO/ORG WIRE
W/ DRL
W/ KEYLESS ENTRY
