Ford Explorer III (2001-2006) transfer case high to low relay transfer case low to high relay Wiring diagrams
This page contains all the electrical diagrams for the component. transfer case high to low relay transfer case low to high relay, in which he is found in the car Ford Explorer III (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
transfer case high to low relay transfer case low to high relay wiring diagram (1 of 2)
4.0L
4.6L
A/C CLUTCH CYCLING PRESSURE SWITCH
A/C CLUTCH SOLENOID
A/C HIGH PRESSURE SWITCH
A/C INDICATOR DIODE
ABS CONTROL MODULE
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS (DRL) MODULE
DAYTIME RUNNING LAMPS (DRL) RELAY
DIGITAL TRANSMISSION RANGE (DTR) SENSOR
EXPLORER
FOG LAMP RELAY
FUEL PUMP RELAY
HIGH BEAM RELAY
HIGH RIGHT FRONT PARK/TURN LAMP BEAM LAMP
IGNITION RELAY
JUNCTION EXTENSION HARNESS, NEAR BREAKOUT TO LEFT HEADLAMP)
LEFT FRONT FOG LAMP
LEFT FRONT HIGH BEAM LAMP
LEFT FRONT LOW BEAM LAMP
LEFT FRONT PARK/TURN LAMP LEFT HEADLAMP
LEFT FRONT SIDE LAMP
LEFT HORN
LEFT REPEATER LAMP LEFT FRONT PARK/TURN LAMP
LT BLU WIRE
LT GRN WIRE
MASS AIR FLOW (MAF SENSOR)
MOUNTAINEER
NCA WIRE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT
RIGHT FRONT FOG LAMP RIGHT REPEATER LAMP
RIGHT FRONT LOW BEAM LAMP RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP RIGHT HEADLAMP
RIGHT FRONT SIDE LAMP
RIGHT HORN
SHIELD
TRANSFER CASE HIGH TO LOW RELAY TRANSFER CASE LOW TO HIGH RELAY
WASHER FLUID LEVEL SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> TRANSFER CASE HIGH TO LOW RELAY TRANSFER CASE LOW TO HIGH RELAY
transfer case high to low relay transfer case low to high relay wiring diagram (2 of 2)
ABS CONTROL MODULE
AUXILIARY A/C RELAY
AUXILIARY JUNCTION BOX (AJB)
BATTERY
BATTERY CHARGE RELAY
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPARTMENT, AT FENDER APRON)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLOWER MOTOR RELAY HORN RELAY
BRN WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
CIRCUIT BREAKER 62
CONSOLE 1 POWER POINT (IN CENTER
CONSOLE 2 POWER POINT
CONSOLE)
DK GRN WIRE
ENGINE COMPARTMENT RELAY BOX (AT RIGHT SIDE OF ENGINE COMPARTMENT)
FROM FUSE 6 (BJB) (DIAGRAM FUSE 11 1 OF 4)
FROM FUSE 8 (BJB) (DIAGRAM 1 OF 4)
FUEL PUMP RELAY
FUSE 1
FUSE 12
FUSE 13
FUSE 14 FUSE 18 FUSE 20
FUSE 16
FUSE 17
FUSE 2
FUSE 23
FUSE 26
FUSE 27
FUSE 28 FUSE 36
FUSE 30 FUSE 34
FUSE 33 FUSE 29
FUSE 4
FUSE 5 FUSE 10 FUSE 7
FUSE 6
FUSE 8
FUSE 9
FUSIBLE LINK A
FUSIBLE LINK B (12 GA-
FUSIBLE LINK C
GENERATOR
GRY WIRE
IGNITION RELAY
LEFT TURN TRAILER TOW RELAY
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH VEHICLE SECURITY MODULE (VSM)
NCA WIRE
ORG/ WIRE
PARKING LAMP TRAILER TOW RELAY
PCM POWER RELAY
PNK PNK WIRE
PNK WIRE
REAR AUXILIARY JUNCTION BOX (AJB) (AT RIGHT "D" PILLAR)
REAR WINDOW DEFROST RELAY
REAR WIPER MOTOR ASSEMBLY ADJUSTABLE PEDAL SWITCH
RED WIRE
RED/WHT WIRE
REVERSING LAMP TRAILER TOW RELAY
RIGHT POWER SEAT SWITCH
RIGHT TURN TRAILER TOW RELAY
STARTER MOTOR
STARTER RELAY
TAN WIRE
TO ACCESSORY DELAY RELAY (CJB) (DIAGRAM 3 OF 4)
TO FUSE 10 (CJB) (DIAGRAM 3 OF 4)
TO FUSE 11 (BJB) (DIAGRAM 1 OF 4)
TO FUSE 15 (BJB) (DIAGRAM 3 OF 4)
TO FUSE 16 (CJB) (DIAGRAM 4 OF 4)
TO FUSE 26 (BJB) (DIAGRAM 1 OF 4)
TO FUSE 5 (CJB) (DIAGRAM 3 OF 4)
TO IGNITION SWITCH (DIAGRAM 2 OF 4)
TRAILER TOW
TRANSFER CASE HIGH TO LOW RELAY
TRANSFER CASE HIGH TO LOW RELAY TRANSFER CASE LOW TO HIGH RELAY
TRANSFER CASE LOW TO HIGH RELAY
VEHICLE SECURITY MODULE (VSM)
VIO WIRE
WHT WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> Power distribution circuit (1 of 4) -> TRANSFER CASE HIGH TO LOW RELAY TRANSFER CASE LOW TO HIGH RELAY
