Ford Explorer III (2001-2006) sta ignition switch Wiring diagram
This page shows the only wiring diagram for the component.sta ignition switch, which is found in the car Ford Explorer III (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sta ignition switch (1 of 1)
BATTERY (AT LEFT FRONT OF ENGINE COMPT)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
CHARGING CIRCUIT
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (AT CENTER OF AUTOMATIC TRANSMISSION)
DK BLU WIRE
FUSE 14 FUSE 8
FUSE 24
LOCK OFF
LT BLU WIRE
ORG/ WIRE
PNK WIRE
POWERTRAIN CONTROL MODULE (PCM)
RED WIRE
RUN WIRE
STA IGNITION SWITCH
STARTER MOTOR (ON LEFT REAR OF ENGINE)
TAN WIRE
WHT WIRE
YEL WIRE
Go to component -> Starting circuit -> STA IGNITION SWITCH
