Ford Explorer III (2001-2006) right turn trailer tow relay left turn trailer tow relay Wiring diagrams
This page contains all the electrical diagrams for the component. right turn trailer tow relay left turn trailer tow relay, in which he is found in the car Ford Explorer III (2001-2006). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right turn trailer tow relay left turn trailer tow relay (1 of 2)
ABS CONTROL MODULE
AUTO
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRAKE PEDAL RELAY (EARLY PRODUCTION)
BRN WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DK BLU/WHT WIRE
DK GRN WIRE
FUSE 21
FUSE 25 FUSE 16
FUSE 5
HAZARD
HEAD PARK OFF
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
HOT IN RUN OR START
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
J/C 4
LEFT FRONT PARK/ TURN LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/ STOP/ TURN LAMP
LEFT TURN
LEFT TURN SIGNAL IND RIGHT TURN SIGNAL IND
LT BLU WIRE
LT BLU/RED WIRE
LT GRN WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
MAIN LIGHT SWITCH
MICRO- PROCESSOR
MULTI- FUNCTION SWITCH
NCA WIRE
ORG/ WIRE
PARKING LAMP TRAILER TOW RELAY
PWR
REAR AUXILIARY JUNCTION BOX (AJB) (AT RIGHT "D" PILLAR)
REAR AUXILIARY JUNCTION BOX (AJB) (AT RIGHT "D" PILLAR) J/C 3
RED/LT GRN WIRE
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/ STOP/ TURN LAMP
RIGHT TURN
RIGHT TURN TRAILER TOW RELAY LEFT TURN TRAILER TOW RELAY
TAN WIRE
TAN/WHT WIRE
TRAILER ELECTRONIC BRAKE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
VEHICLE SECURITY MODULE(VSM) (ABOVE RIGHT REAR WHEELWELL)
VIO/WHT WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
WIPER MOTOR
Go to component -> Exterior lamps circuit, with ivd -> RIGHT TURN TRAILER TOW RELAY LEFT TURN TRAILER TOW RELAY
Wiring diagram right turn trailer tow relay left turn trailer tow relay (2 of 2)
BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
BRN/YEL WIRE
CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH)
DK BLU/WHT WIRE
DK GRN WIRE
FUSE 16
FUSE 21
FUSE 25
FUSE 5
HAZARD
HEAD
HIGH MOUNTED STOPLAMP
HOT AT ALL TIMES
HOT IN RUN OR START
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
J/C 4
JUNCTION BOX
LEFT FRONT PARK/ TURN LAMP
LEFT LICENSE PLATE LAMP
LEFT REAR PARK/ STOP/ TURN LAMP
LEFT TURN
LT BLU WIRE
LT BLU/RED WIRE
LT GRN WIRE
LT GRN/ORG WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
MAIN LIGHT SWITCH
MICRO- PROCESSOR
MULTI- FUNCTION SWITCH
NCA WIRE
PARK AUTO OFF
PARKING LAMP TRAILER TOW RELAY
PWR
REAR AUXILIARY JUNCTION BOX (AJB) (AT RIGHT "D" PILLAR)
REAR AUXILIARY JUNCTION BOX (AJB) (AT RIGHT "D" PILLAR) J/C 3
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE PLATE LAMP
RIGHT REAR PARK/ STOP/ TURN LAMP
RIGHT TURN
RIGHT TURN SIGNAL IND LEFT TURN SIGNAL IND
RIGHT TURN TRAILER TOW RELAY LEFT TURN TRAILER TOW RELAY
SWITCH ASSEMBLY
TAN/BLK WIRE
TAN/WHT WIRE
TRAILER ELECTRONIC BRAKE CONTROL MODULE (BEHIND RIGHT SIDE OF DASH)
VEHICLE SECURITY MODULE(VSM) (ABOVE RIGHT REAR WHEELWELL)
VIO/WHT WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
Go to component -> Exterior lamps circuit, without ivd -> RIGHT TURN TRAILER TOW RELAY LEFT TURN TRAILER TOW RELAY
