Ford Explorer III (2001-2006) off off map lamps Wiring diagram
This page shows the only wiring diagram for the component.off off map lamps, which is found in the car Ford Explorer III (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram off off map lamps (1 of 1)
BLK WIRE
BLK/LT BLU WIRE
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FRONT INTERIOR/ MAP LAMPS ASSEMBLY INTERIOR LAMP
HOMELINK MODULE VPWR
INTERIOR LAMP ON
LEFT VANITY MIRROR LAMP
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
OFF
OFF MAP LAMPS
OFF OFF MAP LAMPS
ORG/ WIRE
RIGHT VANITY MIRROR LAMP
W/ MEDIUM OVERHEAD CONSOLE
W/O MEDIUM OVERHEAD CONSOLE
Go to component -> Courtesy lamps circuit, except base (2 of 2) -> OFF OFF MAP LAMPS
