Ford Explorer III (2001-2006) junction extension harness, near breakout to left headlamp) Wiring diagram
This page shows the only wiring diagram for the component.junction extension harness, near breakout to left headlamp), which is found in the car Ford Explorer III (2001-2006). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram junction extension harness, near breakout to left headlamp) (1 of 1)
4.0L
4.6L
A/C CLUTCH CYCLING PRESSURE SWITCH
A/C CLUTCH SOLENOID
A/C HIGH PRESSURE SWITCH
A/C INDICATOR DIODE
ABS CONTROL MODULE
BATTERY
BLK WIRE
BLOWER MOTOR RELAY
BRAKE FLUID LEVEL SWITCH
DATA LINK CONNECTOR (DLC)
DAYTIME RUNNING LAMPS (DRL) MODULE
DAYTIME RUNNING LAMPS (DRL) RELAY
DIGITAL TRANSMISSION RANGE (DTR) SENSOR
EXPLORER
FOG LAMP RELAY
FUEL PUMP RELAY
HIGH BEAM RELAY
HIGH RIGHT FRONT PARK/TURN LAMP BEAM LAMP
IGNITION RELAY
JUNCTION EXTENSION HARNESS, NEAR BREAKOUT TO LEFT HEADLAMP)
LEFT FRONT FOG LAMP
LEFT FRONT HIGH BEAM LAMP
LEFT FRONT LOW BEAM LAMP
LEFT FRONT PARK/TURN LAMP LEFT HEADLAMP
LEFT FRONT SIDE LAMP
LEFT HORN
LEFT REPEATER LAMP LEFT FRONT PARK/TURN LAMP
LT BLU WIRE
LT GRN WIRE
MASS AIR FLOW (MAF SENSOR)
MOUNTAINEER
NCA WIRE
PCM POWER RELAY
POWERTRAIN CONTROL MODULE (PCM)
RIGHT FRONT
RIGHT FRONT FOG LAMP RIGHT REPEATER LAMP
RIGHT FRONT LOW BEAM LAMP RIGHT FRONT FOG LAMP
RIGHT FRONT PARK/TURN LAMP RIGHT HEADLAMP
RIGHT FRONT SIDE LAMP
RIGHT HORN
SHIELD
TRANSFER CASE HIGH TO LOW RELAY TRANSFER CASE LOW TO HIGH RELAY
WASHER FLUID LEVEL SWITCH
WHT WIRE
WINDSHIELD WIPER MOTOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 4) -> JUNCTION EXTENSION HARNESS, NEAR BREAKOUT TO LEFT HEADLAMP)
