Ford Explorer III (2001-2006) central security module indicator flasher relay Wiring diagram

A/C CLUTCH RELAY AUTOLAMP HEADLAMP RELAY MAIN LIGHT SWITCH AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH, NEAR STEERING COLUMN) BATTERY BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLOWER MOTOR RELAY STARTER RELAY TRAILER TOW RELAY BRAKE PEDAL POSITION SWITCH BRAKE PEDAL POSITION SWITCH SUBWOOFER AMPLIFIER BRN WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) CENTRAL SECURITY DOOR UNLOCK RELAY MODULE CENTRAL SECURITY MODULE INDICATOR FLASHER RELAY COMPT, AT FENDER APRON) DAYTIME RUNNING LAMPS (DRL) MODULE ABS CONTROL MODULE DK BLU WIRE DK GRN WIRE DOOR LOCK RELAY DRIVER SIDE FRONT SEAT ADJUST SWITCH LEFT FRONT LUMBAR ADJUST SWITCH EXTERIOR REAR VIEW MIRROR SWITCH FOG LAMP RELAY FOUR WHEEL DRIVE CONTROL MODULE FROM FUSE 15 (DIAGRAM 1 OF 2) FROM FUSE 34 (DIAGRAM 1 OF 2) FUEL PUMP RELAY FUSE FUSE 1 FUSE 10 FUSE 11 FUSE 14 FUSE 15 FUSE 20 FUSE 22 FUSE 24 FUSE 26 FUSE 27 FUSE 16 FUSE 18 FUSE 28 FUSE 29 FUSE 31 FUSE 34 FUSE 35 FUSE 5 FUSE 8 FUSE 7 FUSE 23 FUSE 9 FUSE 9 FUSE 13 FUSE FUSE 3 FUSIBLE LINK A (12 GA- FUSIBLE LINK B (12 GA- FUSIBLE LINK C (18 GA- GENERATOR GRY WIRE HARNESS, NEAR BREAKOUT UNDER DRIVER SEAT) HEATED SEATS RELAY PASSENGER SIDE FRONT SEAT ADJUST SWITCH HORN RELAY LT BLU WIRE LT GRN WIRE MAIN LIGHT SWITCH AUTOLAMP HEADLAMP RELAY CENTRAL SECURITY MODULE MULTI- FUNCTION SWITCH RIGHT FRONT LUMBAR ADJUST SWITCH NCA WIRE ORG/ WIRE PNK PNK WIRE PNK WIRE POWERTRAIN CONTROL MODULE (PCM) REAR POWER POINT (REAR OF VEHICLE, ON LEFT SIDE) REAR WINDOW MOTOR RED WIRE ROOF OPENING PANEL MODULE STARTER MOTOR SUBWOOFER AMPLIFIER TAN WIRE TO FUSE 1 (DIAGRAM 1 OF 2) TO FUSE 14 (DIAGRAM 1 OF 2) TO FUSE 25 (DIAGRAM 2 OF 2) VIO WIRE WHT WIRE WHT/YEL WIRE WINDOW SAFETY RELAY WINDSHIELD WIPER RELAY XLS XLT XLT XLS YEL WIRE YEL/LT BLU WIRE
