Ford Explorer III (2001-2006) 10 4 3 5 7 memory set sw memory set sw memory set sw memory set sw adj pedal pot Wiring diagram

10 4 3 5 7 MEMORY SET SW MEMORY SET SW MEMORY SET SW MEMORY SET SW ADJ PEDAL POT 12 10 ADJ PEDAL MTR ADJ PEDAL MTR 13 19 POS SENS - POS SENS + 2 1 GROUND POWER 9 8 ADJ PEDAL SW ADJ PEDAL SW ADJUSTABLE PEDAL MEMORY POTENTIOMETER (UNDER DRIVER'S SIDE OF DASH) ADJUSTABLE PEDAL MOTOR (ON PEDAL ASSEMBLY, LEFT OF BRAKE PEDAL) ADJUSTABLE PEDAL SWITCH BLK WIRE BLK/LT BLU WIRE BLK/ORG WIRE BLU WIRE BRN/LT GRN WIRE BRN/ORG WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) FUSE 1 DK GRN WIRE DRIVER SEAT MODULE (IN DRIVER'S SEAT) FORWARD/ HOT AT ALL TIMES LEFT POWER SEAT MOTOR ASSEMBLY (IN DRIVER SEAT) LT BLU WIRE LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE MEMORY SEATS CIRCUIT ORG/ WIRE ORG/RED WIRE ORG/WHT WIRE PNK/BLK WIRE REARWARD RED WIRE RED/BLK WIRE WHT WIRE WHT/ORG WIRE YEL WIRE
