Ford Explorer III (2001-2006) 1 2 3 4 5 6 7 8 high audio + high audio - shield mute Wiring diagram

1 2 3 4 5 6 7 8 HIGH AUDIO + HIGH AUDIO - SHIELD MUTE ANTENNA BATTERY JUNCTION BOX (BJB) (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BLK/LT GRN WIRE BLK/WHT WIRE BRN/ORG WIRE BRN/PNK WIRE CENTRAL JUNCTION BOX (CJB) (BEHIND LEFT SIDE OF DASH) DK GRN/ORG WIRE DK GRN/VIO WIRE FUSE 13 FUSE 28 FUSE 29 FUSE 39 GRY/LT BLU WIRE HOT AT ALL TIMES HOT IN HOT W/ WINDOW SAFETY RELAY ENERGIZED L FRONT SPKR (-) L REAR SPKR (-) R REAR SPKR (-) LEFT FRONT SPEAKER RIGHT FRONT SPEAKER LEFT REAR SPEAKER LT BLU WIRE LT BLU/WHT WIRE LT GRN WIRE LT GRN/VIO WIRE MUTE NCA WIRE ORG/LT GRN WIRE ORG/RED WIRE POWER WINDOWS SYSTEM RADIO RED WIRE RED/BLK WIRE RIGHT REAR SPEAKER SUBWOOFER SUBWOOFER AMPLIFIER (NEAR RIGHT SIDE OF REAR WINDOW) TAN/YEL WIRE TWISTED PAIR VBATT VIO WIRE VIO/LT BLU WIRE VPWR WHT WIRE WHT/LT GRN WIRE WHT/VIO WIRE
