Starting circuit for Ford Explorer II (1994-2003)
Starting circuit
A/T
BATTERY
BATTERY JUNCTION BOX (LEFT REAR OF ENGINE COMPT)
BATTERY JUNCTION BOX (LEFT REAR OF ENGINE COMPT) STARTER RELAY
BLK WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CLUTCH PEDAL POSITION SWITCH (ABOVE CLUTCH PEDAL)
DIGITAL TRANSMISSION RANGE (DTR) SENSOR (LEFT SIDE OF TRANSMISSION)
DK BLU WIRE
DK BLU/ORG WIRE
EARLY PRODUCTION
FUSE 11
FUSE 24
IGNITION SWITCH STA
LATE PRODUCTION
LOCK OFF
M/T
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER MODULE (BEHIND TOP RIGHT SIDE OF DASH)
PNK WIRE
POWERTRAIN CONTROL MODULE
RED WIRE
RED/LT BLU WIRE
RUN WIRE
STARTER MOTOR
TAN/RED WIRE
WHT/PNK WIRE
YEL WIRE
YEL/LT BLU WIRE
