Radio circuits, without amplifier for Ford Explorer II (1994-2003)
Radio circuits, without amplifier
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 ILLUM RETURN GROUND FUSED IGNITION
ANTENNA
ANTI-LOCK BRAKES
BLK WIRE
BLK/LT GRN WIRE
BRN/PNK WIRE
DK GRN/ORG WIRE
FUSE 20
FUSE 29
FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) FUSE 28
GRY/BLK WIRE
GRY/LT BLU WIRE
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR ACC
LEFT FRONT SPEAKER LEFT REAR SPEAKER
LT BLU/WHT WIRE
LT GRN WIRE
LT GRN/VIO WIRE
NCA WIRE
ORG/LT GRN WIRE
ORG/RED WIRE
RADIO
RED WIRE
RED/BLK WIRE
RIGHT FRONT SPEAKER RIGHT REAR SPEAKER
TAN/YEL WIRE
VEHICLE SPEED
VIO WIRE
WHT/LT GRN WIRE
YEL WIRE
YEL/BLK WIRE
