Power top/sunroof circuits for Ford Explorer II (1994-2003)
Power top/sunroof circuits
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/PNK WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DOWN/ OPEN
FUSE 12 (SPORT) (SPORT TRAC)
FUSE 20
GRN WIRE
HOT AT ALL TIMES
HOT IN RUN OR ACC
PNK WIRE
RED WIRE
ROOF OPENING PANEL MODULE (AT FRONT CENTER OF ROOF)
ROOF OPENING PANEL SWITCH
UP/ CLOSE
YEL WIRE
YEL/GRN WIRE
