Automatic day/night mirror circuit for Ford Explorer II (1994-2003)
Automatic day/night mirror circuit
BLK WIRE
BLK/PNK WIRE
DAY/NIGHT MIRROR/ AUTOLAMP SENSOR (MOUNTED IN REARVIEW MIRROR)
DIGITAL TRANSMISSION RANGE SENSOR
EXTERIOR LIGHTS SYSTEM (PARK LAMP RELAY)
FUSE
FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH)
HOT AT ALL TIMES
HOT IN
HOT IN RUN OR START
LT GRN/YEL WIRE
RED/YEL WIRE
REVERSING LAMP SWITCH
RUN WIRE
VIO/ORG WIRE
WHT/VIO WIRE
