Courtesy lamps circuit, late production for Ford Explorer II (1994-2003)
Courtesy lamps circuit, late production
AUXILIARY RELAY BOX 2 (UNDER LEFTR SIDE OF DASH)
BATTERY SAVER RELAY
BLK WIRE
BLK/LT BLU WIRE
BLK/PNK WIRE
CARGO LAMP ASSEMBLY
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DRIVER SIDE FRONT DOOR AJAR SWITCH
DRIVER SIDE REAR DOOR AJAR SWITCH
FRONT INTERIOR/ MAP LAMPS ASSEMBLY
FUSE 26
GENERIC ELECTRONIC MODULE (GEM) (BEHIND CENTER OF DASH)
GLOVE BOX LAMP)
GRY/RED WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL DIMMING MODULE (LEFT SIDE OF STEERING COLUMN)
INTERIOR LAMPS RELAY
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
LT GRN/YEL WIRE
NCA WIRE
NORM
ON OFF
ORG/ WIRE
OVERHEAD CONSOLE
PASSENGER SIDE FRONT DOOR AJAR SWITCH
PASSENGER SIDE REAR DOOR AJAR SWITCH
PNK/LT BLU WIRE
REAR INTERIOR/ MAP LAMPS ASSEMBLY
TAN/YEL WIRE
VIO WIRE
VIO/ORG WIRE
W/ OVERHEAD CONSOLE
W/O OVERHEAD CONSOLE
YEL/BLK WIRE
