Horn circuit for Ford Explorer II (1994-2003)
Horn circuit
AIR BAG SLIDING CONTACT
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON)
BLK WIRE
BLK/WHT WIRE
CENTRAL SECURITY MODULE (BEHIND TOP RIGHT SIDE OF DASH)
COMPT)
DK BLU WIRE
EARLY PRODUCTION
FUSE 22
GRN WIRE
HORN (RIGHT FRONT OF ENGINE
HORN RELAY
HORN SWITCH
HOT AT ALL TIMES
LATE PRODUCTION
LT BLU WIRE
NCA WIRE
STEERING WHEEL/ SPEED CONTROL SWITCH
W/ ANT- THEFT
W/ CRUISE CONTROL
W/O ANTI- THEFT
W/O CRUISE CONTROL
YEL WIRE
YEL/GRN WIRE
