Trailer tow circuit for Ford Explorer II (1994-2003)
Trailer tow circuit
AUXILIARY RELAY
BLK WIRE
BOX 2 (UNDER LEFT SIDE OF DASH) TRAILER TOW RELAY
BRN/WHT WIRE
DK GRN WIRE
DK GRN/YEL WIRE
EXTERIOR LIGHT CIRCUIT
HEAD OFF
HOT AT ALL TIMES BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) FUSE 33
HOT AT ALL TIMES CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FUSE 36
MAIN LIGHT SWITCH
ORG/ WIRE
PARK
TAN/WHT WIRE
TRAILER TOW CONNECTOR
WHT/BLK WIRE
