Computer data lines, late production for Ford Explorer II (1994-2003)
Computer data lines, late production
4-WHEEL DRIVE CONTROL MODULE (AT RIGHT KICK PANEL)
ABS CONTROL MODULE (ON LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CENTRAL SECURITY MODULE (BEHIND TOP RIGHT SIDE OF DASH)
DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH)
FUSE 17
GENERIC ELECTRONIC MODULE (GEM) (BEHIND CENTER OF DASH)
HOT AT ALL TIMES
LT BLU WIRE
LT BLU/WHT WIRE
NOT USED
PNK/LT BLU WIRE
POWERTRAIN CONTROL MODULE (PCM) (MOUNTED THROUGH FIREWALL)
RESTRAINTS CONTROL MODULE (RCM) (BEHIND LOWER CENTER OF DASH)
TAN/ORG WIRE
VIO WIRE
WHT WIRE
