Passive anti-theft circuit, late production for Ford Explorer II (1994-2003)
Passive anti-theft circuit, late production
ANTI- THEFT IND
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
FUSE 19
GRY/ORG WIRE
HOT IN RUN OR START
INSTRUMENT CLUSTER
LT GRN WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER (IN STEERING COLUMN)
POWERTRAIN CONTROL MODULE (MOUNTED THROUGH FIREWALL)
RED WIRE
RED/LT GRN WIRE
STARTER RELAY
WHT WIRE
WHT/LT GRN WIRE
