Passive anti-theft circuit, early production for Ford Explorer II (1994-2003)
Passive anti-theft circuit, early production
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STARTER RELAY
ANTI- THEFT IND
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK/WHT WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (BEHIND CENTER OF DASH) (FRONT LEFT SIDE OF CENTER CONSOLE)
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK GRN/WHT WIRE
FUSE 19
FUSE 25
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
PASSIVE ANTI-THEFT TRANSCEIVER (IN STEERING COLUMN)
PASSIVE ANTI-THEFT TRANSCEIVER MODULE (BEHIND TOP RIGHT SIDE OF DASH)
PNK/LT BLU WIRE
RED/LT GRN WIRE
RF, POWER RX, SIGNAL
SCP BUS (-) SCP BUS (+) GROUND PATS IND
STARTER RELAY
TAN/ORG WIRE
TX, SIGNAL GROUND BATTERY IGNITION
WHT/LT GRN WIRE
WHT/YEL WIRE
