Passive anti-theft circuit for Ford Explorer II (1994-2003)
Passive anti-theft circuit
ANTI- THEFT IND
ANTI-THEFT TRANSCEIVER MODULE (BEHIND CENTER OF DASH)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BUS (-) BUS (+) GROUND PATS IND
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH) ENGINE CONTROL MODUEL
DK BLU WIRE
DK BLU/LT GRN WIRE
DK GRN/WHT WIRE
FUSE 19
FUSE 25
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
LT GRN WIRE
PASSIVE ANTI-THEFT SYSTEM (PATS) MODULE (BEHIND TOP RIGHT SIDE OF DASH)
PNK/ LT BLU WIRE
PNK/LT BLU WIRE
RED WIRE
RED/LT GRN WIRE
RF POWER RECEIVE
TAN/ORG WIRE
TRANSMIT GROUND BATTERY IGNITION
W/ EATC
W/O EATC
WHT WIRE
WHT/LT GRN WIRE
WHT/YEL WIRE
YEL WIRE
