Ford Explorer II (1994-2003) w/ convenience group w/o convenience group Wiring diagrams
This page contains all the electrical diagrams for the component. w/ convenience group w/o convenience group, in which he is found in the car Ford Explorer II (1994-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ convenience group w/o convenience group (1 of 2)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
AUXILIARY RELAY BOX 3 (ON LEFT SIDE OF REAR CARGO COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 5
FUSE 7
HAZARD
HEAD OFF
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY
RED WIRE
REMOTE ANTI-THEFT PERSONALITY MODULE (AT LEFT REAR QUARTER PANEL)
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
VIO/WHT WIRE
W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, early production -> W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
Wiring diagram w/ convenience group w/o convenience group (2 of 2)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CENTRAL SECURITY MODULE (BEHIND TOP RIGHT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 5
FUSE 7
HAZARD
HEAD OFF
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY (AT RIGHT KICK PANEL)
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
VIO/WHT WIRE
W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, late production -> W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
