Ford Explorer II (1994-2003) subwoofer amplifier high mounted stop lamp wiring diagram
This page shows the only wiring diagram for the component.subwoofer amplifier high mounted stop lamp, which is found in the car Ford Explorer II (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
subwoofer amplifier high mounted stop lamp wiring diagram (1 of 1)
AUXILIARY RELAY BOX 2
BLK WIRE
DATA LINK CONNECTOR
EARLY PROD
EARLY PRODUCTION
FOUR WHEEL DRIVE CONTROL MODULE
FUEL TANK UNIT
FUEL TANK UNIT REAR WINDOW MOTOR
GENERIC ELECTRONIC MODULE
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LATE PROD
LATE PRODUCTION
LEFT LIFTGATE AJAR SWITCH
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER MODULE
RADIO
REAR INTEGRATED CONTROL PANEL
REAR WINDOW ADJUST SWITCH
REAR WINDOW MOTOR
REMOTE ANTI-THEFT PERSONALITY MODULE
RESTRAINTS CONTROL MODULE
RIGHT LIFTGATE AJAR SWITCH REAR WIPER MOTOR ASSEMBLY
ROOF OPENING PANEL MODULE REAR WINDOW DEFROST GRID
SPORT TRAC, EARLY PRODUCTION
SPORT, EARLY PRODUCTION
SUBWOOFER AMPLIFIER HIGH MOUNTED STOP LAMP
W/ CONVENIENCE GROUP
W/ SPORT TRAC
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 4) -> SUBWOOFER AMPLIFIER HIGH MOUNTED STOP LAMP
