Ford Explorer II (1994-2003) rear wiper down relay Wiring diagrams
This page contains all the electrical diagrams for the component. rear wiper down relay, in which he is found in the car Ford Explorer II (1994-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear wiper down relay (1 of 2)
4 WHEEL ANTI- LOCK BRAKE SYSTEM MODULE
A/C RELAY
AIR SUSPENSION SWITCH
AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLOWER MOTOR RELAY
DAYTIME RUNNING LAMPS MODULE
DK BLU WIRE
DK GRN WIRE
FOG LAMP RELAY AIR SUSPENSION CONTROL RELAY
FROM FUSE 1 (DIAGRAM 1 OF 5)
FROM FUSE 12 (DIAGRAM 1 OF 5)
FUEL PUMP RELAY
FUSE 1
FUSE 10
FUSE 11 MAXI FUSE 4
FUSE 14
FUSE 3 FUSE 12
FUSE 4 MAXI FUSE 9
FUSE 5 (NOT USED)
FUSE 6
FUSE 7
FUSE 8 REAR WIPER UP RELAY
FUSE 9
GENERATOR
HEADLAMP RELAY
HEADLAMP RELAY ACCY DELAY RELAY
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH DIMMER RELAY
MAXI FUSE 2
MAXI FUSE 3 HORN RELAY
MAXI FUSE 6
MAXI FUSE 8
MEGA FUSE
MOONROOF MOTOR ELECTRIC SHIFT CONTROL MODULE
MULTI- FUNCTION SWITCH
ORG/ WIRE
PARK LAMP RELAY
PNK WIRE
POWERTRAIN CONTROL MODULE
PPL
PPL PPL
REAR WINDOW DEFROST RELAY MAIN LIGHT SWITCH
REAR WIPER DOWN RELAY
RED WIRE
RELAY MODULE (BEHIND CENTER OF DASH)
REMOTE ANTI-THEFT PERSONALITY MODULE
STARTER MOTOR
TAN WIRE
TO FUSE 10 (DIAGRAM 1 OF 5)
TO FUSE 5 (DIAGRAM 2 OF 5)
TO FUSE 9 (DIAGRAM 1 OF 5)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> REAR WIPER DOWN RELAY
Wiring diagram rear wiper down relay (2 of 2)
21 20 12 19 (LATE PRODUCTION)
4 17 (LATE PRODUCTION)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY JUNCTION BOX (NEAR LEFT FENDER APRON)
BLK WIRE
BLK/LT BLU WIRE
BLK/WHT WIRE
BRN/WHT WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
FRONT WASHER PUMP RELAY
FRONT WIPER/WASHER CIRCUIT
FUSE 12
FUSE 34
GENERIC ELECTRONIC MODULE (BEHIND CENTER OF DASH)
GRN WIRE
HOT AT ALL TIMES
HOT IN ACC OR RUN
ILLUMINATION
LATE PRODUCTION
LEFT LIFTGATE AJAR SWITCH
LIFTGATE DISABLE/AJAR
LIFTGATE WIPER DISABLE SWITCH
LIFTGATE WIPER MOTOR
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK/BLK WIRE
REAR WASHER PUMP RELAY
REAR WINDOW WIPER/ WASHER SWITCH
REAR WIPER DOWN CONTROL
REAR WIPER DOWN RELAY
REAR WIPER PARK SENSE
REAR WIPER UP CONTROL
REAR WIPER UP RELAY
RED WIRE
RED/BLK WIRE
RIGHT LIFTGATE AJAR SWITCH
SIGNAL RETURN REAR WIPER MODE SELECT
TAN WIRE
VIO WIRE
VIO/LT GRN WIRE
VIO/YEL WIRE
WASHER PUMP MOTOR (IN WASHER RESERVOIR)
WHT WIRE
WHT/BLK WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
WHT/VIO WIRE
Go to component -> Rear washer/wiper circuit -> REAR WIPER DOWN RELAY
