Ford Explorer II (1994-2003) pwr gnd case gnd ign coil shift sol a shift sol d trans ctrl sw Wiring diagram

AIR CONDITIONING AIR CONDITIONING SYSTEM (HTR-A/C ASSY) AIR SUSP INPUT BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT LEFT FENDER APRON) BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN/ORG WIRE BRN/PNK WIRE CRANKSHAFT POSITION SENSOR SHIELD DATA LINK (-) DATA LINK (+) DATA LINK CONNECTOR (BEHIND LEFT SIDE OF DASH) 10 2 DK BLU WIRE DK BLU/YEL WIRE DK GRN/YEL WIRE ELECTRONIC SUSPENSION SYSTEM EVR CTRL TACHOMETER FUEL LEVEL IN DATA LINK FUSE 10 FUSE 19 FUSE 27 FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) GEM GRY WIRE HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR START IGNITION COIL (ABOVE VALVE COVER) INSTRUMENT CLUSTER SYSTEM LT BLU/BLK WIRE LT GRN/RED WIRE MAF SIG RTN TRANS TEMP ECT SENS IAT SENS FUEL PUMP MON A/C NCA WIRE ORG/BLK WIRE ORG/YEL WIRE OSS + PCM POWER DIODE PCM POWER RELAY PNK/LT BLU WIRE PNK/LT GRN WIRE POWERTRAIN CONTROL MODULE (PCM) (MOUNTED THROUGH FIREWALL) PWR GND CASE GND IGN COIL SHIFT SOL A SHIFT SOL D TRANS CTRL SW PWR GND IGN COIL RADIO NOISE CAPACITOR (LEFT OF IGNITION COIL) RED WIRE RED/LT GRN WIRE SPARK PLUGS TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/WHT WIRE TAN/YEL WIRE TRANSMISSION CONTROL SWITCH VIO WIRE VIO/ORG WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/WHT WIRE
