Ford Explorer II (1994-2003) (power- train control module breakout) wiring diagram
This page shows the only wiring diagram for the component.(power- train control module breakout), which is found in the car Ford Explorer II (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(power- train control module breakout) wiring diagram (1 of 1)
4.0L SOHC V6 4.0L OHV V6
5.0L V8
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
CANISTER VENT SOLENOID
EGR VACUUM REGULATOR SOLENOID
EVAP CANISTER PURGE VALVE
FROM FUSE 8 (DIAGRAM 1 OF 4)
FROM PCM POWER RELAY (4.0L EI V6) (DIAGRAM 2 OF 5)
FROM PCM POWER RELAY (4.0L SOHC V6) (DIAGRAM 2 OF 5)
FROM PCM POWER RELAY (5.0L V8) (DIAGRAM 2 OF 5)
FUEL INJECTOR 1
FUEL INJECTOR 2
FUEL INJECTOR 3
FUEL INJECTOR 4
FUEL INJECTOR 4 FUEL INJECTOR 5
FUEL INJECTOR 5 FUEL INJECTOR 4
FUEL INJECTOR 6
FUEL INJECTOR 7
FUEL INJECTOR 8
FUEL PUMP RELAY A/C RELAY
FUSE 13
HEATED OXYGEN SENSOR 11
HEATED OXYGEN SENSOR 12
HEATED OXYGEN SENSOR 21
HEATED OXYGEN SENSOR 22
IDLE AIR CONTROL VALVE
IDLE AIR CONTROL VALVE MASS AIRFLOW SENSOR
LT BLU/ ORG WIRE
LT BLU/ORG WIRE
MASS AIRFLOW SENSOR
MASS AIRFLOW SENSOR IDLE AIR CONTROL VALVE
MAXI FUSE 1 MAXI FUSE 10
MAXI FUSE 5
NCA WIRE
PCM POWER RELAY
POWER- TRAIN CONTROL MODULE (4.0L OHV)
POWER- TRAIN CONTROL MODULE (4.0L SOHC)
POWER- TRAIN CONTROL MODULE (5.0L V8)
REAR OF ENGINE COMPT)
RED WIRE
STARTER MOTOR RELAY
TAN WIRE
TO FUEL INJECTORS (DIAGRAM 2 OF 5)
TO FUSE 9 (DIAGRAM 3 OF 5)
TO IGNITION SWITCH (DIAGRAM 3 OF 5)
TO PCM POWER DIODE (DIAGRAM 3 OF 5)
TRANS- MISSION
TRANSMISSION
W/ A/T W/ A/T
WHT WIRE
YEL WIRE
