Ford Explorer II (1994-2003) normal Wiring diagrams
This page contains all the electrical diagrams for the component. normal, in which he is found in the car Ford Explorer II (1994-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
normal wiring diagram (1 of 5)
ANTI-THEFT SYSTEM
ANTI-THEFT SYSTEM (RAP MODULE) (1999 ONLY)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
BRN/YEL WIRE
DAY/NIGHT MIRROR/ AUTOLAMP SENSOR (MOUNTED IN REARVIEW MIRROR)
DIMMER RELAY (IN RELAY MODULE)
DK BLU/WHT WIRE
DK GRN WIRE
EXPLORER ONLY
FUSE 10
FUSE 11
FUSE 13
FUSE 21
FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH)
HAZARD
HEAD
HEADLAMP RELAY (IN RELAY MODULE)
HIGH MOUNTED STOP LAMP ASSEMBLY
HOT AT ALL TIMES
HOT IN RUN
IGN (RUN)
INSTRUMENT CLUSTER
LAMPS ON
LEFT FRONT PARK/ TURN LAMPS
LEFT FRONT SIDE MARKER LAMP
LEFT LICENSE LAMP LEFT TURN SIGNAL LAMP (REAR)
LEFT REAR STOP/ PARK LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
LT GRN/ORG WIRE
LT GRN/RED WIRE
LT GRN/WHT WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION
NCA WIRE
NORMAL
OFF
ORG/LT BLU WIRE
ORG/YEL WIRE
PARK
PARK LAMP RELAY (IN RELAY MODULE)
REAR
RED/WHT WIRE
RIGHT FRONT PARK/ TURN LAMPS RIGHT FRONT SIDE MARKER LAMP
RIGHT LICENSE LAMP
RIGHT REAR STOP/ PARK LAMP
RIGHT TURN INDICATOR
RIGHT TURN SIGNAL LAMP
SENSOR OUTPUT
SWITCH
TAN/WHT WIRE
TRAILER TOW PARK LAMP RELAY (W/ TRAILER TOW PACKAGE ONLY)
TRAILER/CAMPER ADAPTER CIRCUIT (STOP/TURN FUSES)
TURN LEFT
TURN RIGHT
TURN/HAZARD CONTROL
TURN/HAZARD FLASHER
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
WHT/LT BLU WIRE
WHT/RED WIRE
WHT/VIO WIRE
Go to component -> Exterior lamps circuit -> NORMAL
normal wiring diagram (2 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
AUXILIARY RELAY BOX 3 (ON LEFT SIDE OF REAR CARGO COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 5
FUSE 7
HAZARD
HEAD OFF
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY
RED WIRE
REMOTE ANTI-THEFT PERSONALITY MODULE (AT LEFT REAR QUARTER PANEL)
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
VIO/WHT WIRE
W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, early production -> NORMAL
normal wiring diagram (3 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BATTERY JUNCTION BOX
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CARGO LAMP ASSEMBLY
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
EARLY PRODUCTION LATE PRODUCTION
FOG LAMP ISOLATION RELAY
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 33
FUSE 7
HAZARD
HEAD OFF
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
W/ FOG LAMPS W/O FOG LAMPS
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, high option content -> NORMAL
normal wiring diagram (4 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CENTRAL SECURITY MODULE (BEHIND TOP RIGHT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 5
FUSE 7
HAZARD
HEAD OFF
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY (AT RIGHT KICK PANEL)
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
VIO/WHT WIRE
W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, late production -> NORMAL
normal wiring diagram (5 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CARGO LAMP ASSEMBLY
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 33
FUSE 7
HAZARD
HEAD OFF
HEADLIGHT SYSTEM
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
NORMAL
ORG/ WIRE
PARK
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, low option content -> NORMAL
