Ford Explorer II (1994-2003) (near breakout to throttle position Wiring diagram

"LOW RANGE" IND INPUT BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) BLK WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE DIFFERENTIAL PRESSURE FEEDBACK EGR (DPFE) SENSOR (REAR OF ENGINE COMPT) DK BLU/YEL WIRE DK GRN/YEL WIRE ENGINE COOLANT TEMPERATURE SENSOR (BEHIND GENERATOR BRACKET) FUEL PUMP FUEL PUMP RELAY FUEL TANK ASSEMBLY FUSE 9 GRY WIRE GRY/ORG WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER LT BLU/BLK WIRE LT BLU/ORG WIRE LT GRN/RED WIRE MALFUNCTION INDICATOR INPUT MESSAGE CENTER NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED (OSS) SENSOR (LEFT REAR OF TRANSMISSION) PNK/BLK WIRE PNK/LT GRN WIRE PRESSURE TRANSDUCER FUEL TANK ASSEMBLY RED WIRE RED/LT GRN WIRE RED/PNK WIRE SENSOR TACH INPUT TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/YEL WIRE TCIL GROUND INPUT THROTTLE POSITION (TP) SENSOR (ON THROTTLE BODY) TO DTR SENSOR (DIAGRAM 4 OF 4) VIO/ORG WIRE WHT/BLK WIRE WHT/LT GRN WIRE YEL/BLK WIRE
