Ford Explorer II (1994-2003) maxi fuse 8 wiring diagram
This page shows the only wiring diagram for the component.maxi fuse 8, which is found in the car Ford Explorer II (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
maxi fuse 8 wiring diagram (1 of 1)
4 WHEEL ANTI- LOCK BRAKE SYSTEM MODULE
A/C RELAY
AIR SUSPENSION SWITCH
AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPARTMENT)
BATTERY
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT)
BLK WIRE
BLOWER MOTOR RELAY
DAYTIME RUNNING LAMPS MODULE
DK BLU WIRE
DK GRN WIRE
FOG LAMP RELAY AIR SUSPENSION CONTROL RELAY
FROM FUSE 1 (DIAGRAM 1 OF 5)
FROM FUSE 12 (DIAGRAM 1 OF 5)
FUEL PUMP RELAY
FUSE 1
FUSE 10
FUSE 11 MAXI FUSE 4
FUSE 14
FUSE 3 FUSE 12
FUSE 4 MAXI FUSE 9
FUSE 5 (NOT USED)
FUSE 6
FUSE 7
FUSE 8 REAR WIPER UP RELAY
FUSE 9
GENERATOR
HEADLAMP RELAY
HEADLAMP RELAY ACCY DELAY RELAY
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH DIMMER RELAY
MAXI FUSE 2
MAXI FUSE 3 HORN RELAY
MAXI FUSE 6
MAXI FUSE 8
MEGA FUSE
MOONROOF MOTOR ELECTRIC SHIFT CONTROL MODULE
MULTI- FUNCTION SWITCH
ORG/ WIRE
PARK LAMP RELAY
PNK WIRE
POWERTRAIN CONTROL MODULE
PPL
PPL PPL
REAR WINDOW DEFROST RELAY MAIN LIGHT SWITCH
REAR WIPER DOWN RELAY
RED WIRE
RELAY MODULE (BEHIND CENTER OF DASH)
REMOTE ANTI-THEFT PERSONALITY MODULE
STARTER MOTOR
TAN WIRE
TO FUSE 10 (DIAGRAM 1 OF 5)
TO FUSE 5 (DIAGRAM 2 OF 5)
TO FUSE 9 (DIAGRAM 1 OF 5)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 5) -> MAXI FUSE 8
