Ford Explorer II (1994-2003) maf sens in tp sens in ref volt sig rtn bpp switch Wiring diagrams

270 OHMS 4-WHEEL ANTI-LOCK BRAKE SYSTEM A/T AIR CONDITIONING SYSTEM (A/C PRESS SW) AIR CONDITIONING SYSTEM (A/C RELAY) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) FUSE 6 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION (CMP) SENSOR (REAR OF ENGINE) CAMSHAFT POSITION SENSOR SHIELD CAN VENT SOL CPP SWITCH DPFE SENS DK BLU/ORG WIRE DK GRN/WHT WIRE FROM DTR SENSOR (DIAGRAM 2 OF 4) FT PRESS SENS FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 FUSE 13 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN HEATER CTRL HOT AT ALL TIMES HOT AT ALL TIMES FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) FUSE 9 IAC SOL TSS CAM POS IN A/C PRESS LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE M/T MAF SENS IN TP SENS IN REF VOLT SIG RTN BPP SWITCH MASS AIRFLOW (MAF) SENSOR (RIGHT SIDE CORNER OF ENGINE COMPT) HEATED OXYGEN NCA WIRE ORG/ WIRE PNK/BLK WIRE PNK/YEL WIRE POWER POWER GND POWERTRAIN CONTROL MODULE (PCM) (MOUNTED THROUGH FIREWALL) REAR AXLE SENSOR (ON AXLE ASSEMBLY) RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR VSS WAC WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE

1999, EARLY PRODUCTION 2000, 2001 270 OHMS 4-WHEEL ANTI-LOCK BRAKE SYSTEM AIR CONDITIONING SYSTEM (A/C PRESS SW) AIR CONDITIONING SYSTEM (A/C RELAY) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT, AT FENDER APRON) FUSE 6 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION (CMP) SENSOR (REAR OF ENGINE) CAN VENT SOL DK BLU/ORG WIRE DK GRN/WHT WIRE DPFE SENS FROM DTR SENSOR (DIAGRAM 1 OF 4) FT PRESS SENS FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 FUSE 13 FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) FUSE 9 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN HEATED OXYGEN (LEFT RADIATOR SUPPORT) HEATER CTRL HOT AT ALL TIMES IAC SOL TSS CMP SENS A/C PRESS LATE PRODUCTION 2000, 2001 LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE MAF SENS IN TP SENS IN REF VOLT SIG RTN BPP SWITCH MASS AIRFLOW (MAF) SENSOR (RIGHT SIDE OF ENGINE COMPT) NCA WIRE ORG/ WIRE PNK/BLK WIRE PNK/YEL WIRE POWER POWER GND POWERTRAIN CONTROL MODULE (PCM) (MOUNTED THROUGH FIREWALL) REAR AXLE SENSOR (ON AXLE ASSEMBLY) RED WIRE RED/BLK WIRE RED/LT BLU WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/YEL WIRE VIO/LT GRN WIRE VIO/WHT WIRE VIO/YEL WIRE VPWR WAC WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE YEL/RED WIRE

270 OHMS 4-WHEEL ANTI-LOCK BRAKE SYSTEM AIR CONDITIONING SYSTEM (A/C PRESS SW) AIR CONDITIONING SYSTEM (A/C RELAY) BATTERY JUNCTION BOX (LEFT SIDE OF ENG COMPT, AT LEFT FENDER APRON) FUSE 6 BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BRN WIRE BRN/LT BLU WIRE BRN/LT GRN WIRE BRN/WHT WIRE BRN/YEL WIRE CAMSHAFT POSITION SENSOR SHIELD CAN VENT SOL DK BLU/ORG WIRE DK BLU/WHT WIRE DK BLU/YEL WIRE DPFE SENS FROM DTR SENSOR (DIAGRAM 2 OF 4) FT PRESS SENS FUSE 13 FUSE JUNCTION PANEL (LEFT SIDE OF VEHICLE, BELOW DASH) FUSE 9 GRY WIRE GRY/BLK WIRE GRY/LT BLU WIRE GRY/RED WIRE GRY/WHT WIRE HEATED OXYGEN HEATED OXYGEN HEATED OXYGEN HEATER CTRL HOT AT ALL TIMES IAC SOL OSS CMP SENS A/C PRESS LT BLU WIRE LT BLU/ORG WIRE LT BLU/RED WIRE LT BLU/YEL WIRE LT GRN/BLK WIRE LT GRN/ORG WIRE MAF SENS IN TP SENS IN REF VOLT SIG RTN BPP SWITCH MASS AIRFLOW (MAF) SENSOR (RIGHT SIDE OF ENGINE COMPT) NCA WIRE ORG/ WIRE PNK/WHT WIRE PNK/YEL WIRE POWER FUEL INJ 8 FUEL INJ 6 FUEL INJ 4 FUEL INJ 2 POWER GND IGN COIL 4 POWERTRAIN CONTROL MODULE (PCM) (MOUNTED THROUGH FIREWALL) REAR AXLE SENSOR (ON AXLE ASSEMBLY) RED WIRE RED/BLK WIRE RED/LT GRN WIRE RED/PNK WIRE RED/WHT WIRE RED/YEL WIRE TAN WIRE TAN/BLK WIRE TAN/LT BLU WIRE TAN/RED WIRE TAN/YEL WIRE TCC SOL KAPWR (+) VAPOR VALVE VIO/LT GRN WIRE VIO/WHT WIRE VSS WHT WIRE WHT/BLK WIRE WHT/LT BLU WIRE WHT/LT GRN WIRE WHT/YEL WIRE YEL WIRE YEL/LT BLU WIRE
