Ford Explorer II (1994-2003) liftgate wiper disable switch Wiring diagrams

12 8 INT LAMP RLY CTRL BAT SAVER RLY CTRL BATTERY SAVER RELAY BLK WIRE BLK/LT BLU WIRE BLK/PNK WIRE CARGO LAMP CENTRAL JUNCTION BOX COMPASS/ OUTSIDE AIR TEMPERATURE MODULE DIMMER MODULE (LEFT SIDE OF STEERING COLUMN) DK GRN WIRE FUSE 26 GLOVE COMPARTMENT LAMP GRN WIRE GRY/RED WIRE HOT AT ALL TIMES INSTRUMENT ILLUMINATION CIRCUIT INTERIOR LAMP INTERIOR LAMP RELAY LEFT FRONT DOOR AJAR SWITCH LEFT LIFTGATE AJAR SWITCH LEFT REAR DOOR AJAR SWITCH LEFT VANITY MIRROR LAMP/SWITCH LIFTGATE WIPER DISABLE SWITCH LT BLU WIRE LT ELECTRIC SHIFT CONTROL MODULE LT GRN WIRE LT GRN/DK GRN WIRE LT GRN/ORG WIRE LT GRN/YEL (OR PNK/LT BLU) WIRE LT GRN/YEL WIRE MAP LAMP NORM ON OFF ORG/ WIRE PNK/LT BLU WIRE POWER WINDOWS CIRCUIT PPL PPL/ORG WIRE REAR INTERIOR LAMP REAR MAP LAMP RELAY MODULE (BEHIND CENTER OF DASH) RIGHT FRONT DOOR AJAR SWITCH RIGHT LIFTGATE AJAR SWITCH RIGHT REAR DOOR AJAR SWITCH RIGHT VANITY MIRROR LAMP/SWITCH TAN/YEL WIRE W/ OVERHEAD CONSOLE W/O OVERHEAD CONSOLE W/O OVERHEAD CONSOLE ONLY WHT WIRE WHT/PPL WIRE YEL/BLK WIRE

21 20 12 19 (LATE PRODUCTION) 4 17 (LATE PRODUCTION) BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPARTMENT) BATTERY JUNCTION BOX (NEAR LEFT FENDER APRON) BLK WIRE BLK/LT BLU WIRE BLK/WHT WIRE BRN/WHT WIRE CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH) FRONT WASHER PUMP RELAY FRONT WIPER/WASHER CIRCUIT FUSE 12 FUSE 34 GENERIC ELECTRONIC MODULE (BEHIND CENTER OF DASH) GRN WIRE HOT AT ALL TIMES HOT IN ACC OR RUN ILLUMINATION LATE PRODUCTION LEFT LIFTGATE AJAR SWITCH LIFTGATE DISABLE/AJAR LIFTGATE WIPER DISABLE SWITCH LIFTGATE WIPER MOTOR LT BLU WIRE LT GRN WIRE ORG/ WIRE PNK/BLK WIRE REAR WASHER PUMP RELAY REAR WINDOW WIPER/ WASHER SWITCH REAR WIPER DOWN CONTROL REAR WIPER DOWN RELAY REAR WIPER PARK SENSE REAR WIPER UP CONTROL REAR WIPER UP RELAY RED WIRE RED/BLK WIRE RIGHT LIFTGATE AJAR SWITCH SIGNAL RETURN REAR WIPER MODE SELECT TAN WIRE VIO WIRE VIO/LT GRN WIRE VIO/YEL WIRE WASHER PUMP MOTOR (IN WASHER RESERVOIR) WHT WIRE WHT/BLK WIRE WHT/LT GRN WIRE WHT/ORG WIRE WHT/VIO WIRE

6 11 14 15 IGN BATTERY IGN IGN BLK WIRE BLK/PNK WIRE BRN/LT BLU WIRE CENTRAL JUNCTION BOX (BEHIND CENTER OF DASH) FUSE 10 FUSE 20 FUSE 25 FUSE 28 GRY WIRE GRY/RED WIRE GRY/YEL WIRE HEAD OFF PARK HOT AT ALL TIMES HOT IN RUN HOT IN RUN OR ACC HOT IN START INSTRUMENT CLUSTER KEY WARNING SWITCH LEFT FRONT DOOR AJAR SWITCH LEFT LIFTGATE AJAR SWITCH LEFT REAR DOOR AJAR SWITCH LIFTGATE WIPER DISABLE SWITCH LT GRN/YEL WIRE MAIN LIGHT SWITCH NCA WIRE PARK LAMP RELAY (IN RELAY MODULE) PNK WIRE PNK/LT BLU WIRE RED WIRE RED/BLK WIRE RIGHT LIFTGATE AJAR SWITCH RIGHT REAR DOOR AJAR SWITCH RIGHT FRONT DOOR AJAR SWITCH SEAT BELT IND SEAT BELT WARNING SWITCH (IN SEAT BELT BUCKLE) WHT WIRE WHT/BLK WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
