Ford Explorer II (1994-2003) instrument panel dimming module Wiring diagrams
This page contains all the electrical diagrams for the component. instrument panel dimming module, in which he is found in the car Ford Explorer II (1994-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram instrument panel dimming module (1 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
AUXILIARY RELAY BOX 3 (ON LEFT SIDE OF REAR CARGO COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 5
FUSE 7
HAZARD
HEAD OFF
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY
RED WIRE
REMOTE ANTI-THEFT PERSONALITY MODULE (AT LEFT REAR QUARTER PANEL)
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
VIO/WHT WIRE
W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, early production -> INSTRUMENT PANEL DIMMING MODULE
Wiring diagram instrument panel dimming module (2 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BATTERY JUNCTION BOX
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CARGO LAMP ASSEMBLY
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
EARLY PRODUCTION LATE PRODUCTION
FOG LAMP ISOLATION RELAY
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 33
FUSE 7
HAZARD
HEAD OFF
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
W/ FOG LAMPS W/O FOG LAMPS
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, high option content -> INSTRUMENT PANEL DIMMING MODULE
Wiring diagram instrument panel dimming module (3 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
CENTRAL SECURITY MODULE (BEHIND TOP RIGHT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 5
FUSE 7
HAZARD
HEAD OFF
HIGH MOUNTED STOP LAMP
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NORMAL
ORG/ WIRE
PARK
PARK LAMP RELAY (AT RIGHT KICK PANEL)
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
VIO WIRE
VIO/WHT WIRE
W/ CONVENIENCE GROUP W/O CONVENIENCE GROUP
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, late production -> INSTRUMENT PANEL DIMMING MODULE
Wiring diagram instrument panel dimming module (4 of 5)
AUXILIARY RELAY BOX 2 (UNDER LEFT SIDE OF DASH)
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK WIRE
BLK/WHT WIRE
BRAKE PEDAL POSITION SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
CARGO LAMP ASSEMBLY
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DK BLU WIRE
DK GRN WIRE
FUSE 10
FUSE 13
FUSE 21
FUSE 3
FUSE 33
FUSE 7
HAZARD
HEAD OFF
HEADLIGHT SYSTEM
HOT AT ALL TIMES
HOT IN RUN
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LEFT
LEFT FRONT PARK/ TURN LAMP
LEFT REAR PARK/ TURN LAMP
LEFT TURN INDICATOR
LT BLU WIRE
LT GRN WIRE
MAIN LIGHT SWITCH
MULTI- FUNCTION SWITCH
NCA WIRE
NORMAL
ORG/ WIRE
PARK
RED WIRE
RIGHT
RIGHT FRONT PARK/ TURN LAMP
RIGHT LICENSE LAMP LEFT LICENSE LAMP
RIGHT REAR PARK/ TURN LAMP
RIGHT TURN INDICATOR
TAN WIRE
TRAILER TOW CONNECTOR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit, low option content -> INSTRUMENT PANEL DIMMING MODULE
Wiring diagram instrument panel dimming module (5 of 5)
AUXILIARY RELAY BOX 2
BLK WIRE
DATA LINK CONNECTOR
EARLY PROD
EARLY PRODUCTION
FOUR WHEEL DRIVE CONTROL MODULE
FUEL TANK UNIT
FUEL TANK UNIT REAR WINDOW MOTOR
GENERIC ELECTRONIC MODULE
INDICATOR FLASHER RELAY
INSTRUMENT CLUSTER
INSTRUMENT PANEL DIMMING MODULE
LATE PROD
LATE PRODUCTION
LEFT LIFTGATE AJAR SWITCH
LT GRN WIRE
NCA WIRE
ORG/ WIRE
PASSIVE ANTI-THEFT TRANSCEIVER MODULE
RADIO
REAR INTEGRATED CONTROL PANEL
REAR WINDOW ADJUST SWITCH
REAR WINDOW MOTOR
REMOTE ANTI-THEFT PERSONALITY MODULE
RESTRAINTS CONTROL MODULE
RIGHT LIFTGATE AJAR SWITCH REAR WIPER MOTOR ASSEMBLY
ROOF OPENING PANEL MODULE REAR WINDOW DEFROST GRID
SPORT TRAC, EARLY PRODUCTION
SPORT, EARLY PRODUCTION
SUBWOOFER AMPLIFIER HIGH MOUNTED STOP LAMP
W/ CONVENIENCE GROUP
W/ SPORT TRAC
WHT WIRE
YEL WIRE
Go to component -> Ground distribution circuit (4 of 4) -> INSTRUMENT PANEL DIMMING MODULE
