Ford Explorer II (1994-2003) check fuel cap indicator mal- function indicator tach input Wiring diagram

"LOW RANGE" INDICATOR BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT) BLK WIRE BLK/WHT WIRE BRN/LT GRN WIRE BRN/ORG WIRE BRN/PNK WIRE BRN/WHT WIRE CHECK FUEL CAP INDICATOR MAL- FUNCTION INDICATOR TACH INPUT DK BLU/YEL WIRE DK GRN/VIO WIRE DK GRN/YEL WIRE ENGINE COOLANT TEMPERATURE SENSOR (LEFT OF THROTTLE BODY) FUEL FLOW RATE INPUT FUEL PUMP FUEL PUMP RELAY FUEL TANK ASSEMBLY FUSE 9 GRY WIRE GRY/ORG WIRE GRY/RED WIRE GRY/WHT WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER KNOCK SENSOR (NEAR INTAKE MANIFOLD) LT BLU/BLK WIRE LT BLU/ORG WIRE LT BLU/PNK WIRE LT GRN/RED WIRE MESSAGE CENTER NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/YEL WIRE OUTPUT SHAFT SPEED (OSS) SENSOR (LEFT REAR OF TRANSMISSION) PNK/BLK WIRE PNK/LT GRN WIRE PRESSURE TRANSDUCER FUEL TANK ASSEMBLY RED WIRE RED/LT BLU WIRE RED/PNK WIRE TACH INPUT TAN/LT BLU WIRE TAN/LT GRN WIRE TAN/YEL WIRE TCIL GROUND INPUT VIO/ORG WIRE WHT/LT GRN WIRE YEL/RED WIRE
