Ford Explorer II (1994-2003) 6 5 4 3 2 1 ignition power ground day/nt mir out relay output Wiring diagram

6 5 4 3 2 1 IGNITION POWER GROUND DAY/NT MIR OUT RELAY OUTPUT AUXILIARY RELAY BOX 1 (LEFT SIDE OF ENGINE COMPT) BATTERY JUNCTION BOX BLK WIRE BLK/PNK WIRE BLK/YEL WIRE BLU WIRE BRAKE FLUID LEVEL WARNING SWITCH (MOUNTED ON LEFT SIDE OF MASTER CYLINDER) BRN WIRE CENTRAL JUNCTION BOX DAYTIME RUNNING LAMPS MODULE (W/ DRL (LEFT FRONT CORNER OF ENGINE COMPT) DIMMER RELAY DIMMER SWITCH DK BLU WIRE DK BLU/LT GRN WIRE DK BLU/ORG WIRE DRL DIODE FLASH TO PASS FOG LAMP RELAY FOG LAMP SWITCH FUSE 11 FUSE 12 FUSE 27 FUSE 33 FUSE 4 FUSE 8 GENERIC ELECTRONIC MODULE (GEM) (BEHIND CENTER OF DASH) GRN WIRE GRY WIRE HEADLAMP RELAY HI LEFT HEADLAMP HI LO LO RIGHT HEADLAMP HOT AT ALL TIMES HOT AT ALL TIMES FUSE 36 HOT IN RUN HOT IN START OR RUN CENTRAL JUNCTION BOX FUSE 11 ILLUM INSTRUMENT CLUSTER INSTRUMENT CLUSTER SYSTEM LEFT FOG LAMP RIGHT FOG LAMP LT BLU/BLK WIRE LT GRN WIRE LT GRN/BLK WIRE LT GRN/RED WIRE LT GRN/YEL WIRE MAIN LIGHT SWITCH MIRROR SYSTEM MULTI- FUNCTION SWITCH OFF HEAD PARK ORG/ WIRE PARK LAMP RELAY PARKING BRAKE SWITCH (ON RIGHT SIDE OF PARKING BRAKE LEVER) PASS HI LO PPL PPL/ORG WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE RELAY MODULE (BEHIND CENTER OF DASH) REMOTE ANTI-THEFT PERSONALITY (RAP) MODULE (AT LEFT REAR QUARTER PANEL) TAN WIRE TAN/ORG WIRE TAN/WHT WIRE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/LT GRN WIRE WHT/PPL WIRE WHT/VIO WIRE YEL WIRE
