Ford Explorer II (1994-2003) 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 starter relay Wiring diagram
This page shows the only wiring diagram for the component.1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 starter relay, which is found in the car Ford Explorer II (1994-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 starter relay (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STARTER RELAY
ANTI- THEFT IND
BATTERY JUNCTION BOX (LEFT SIDE OF ENGINE COMPT)
BLK/WHT WIRE
BLK/YEL WIRE
CENTRAL JUNCTION BOX (BEHIND LEFT SIDE OF DASH)
DATA LINK CONNECTOR (BEHIND CENTER OF DASH) (FRONT LEFT SIDE OF CENTER CONSOLE)
DK BLU/LT GRN WIRE
DK BLU/ORG WIRE
DK GRN/WHT WIRE
FUSE 19
FUSE 25
GRY/ORG WIRE
HOT AT ALL TIMES
HOT IN RUN OR START
INSTRUMENT CLUSTER
PASSIVE ANTI-THEFT TRANSCEIVER (IN STEERING COLUMN)
PASSIVE ANTI-THEFT TRANSCEIVER MODULE (BEHIND TOP RIGHT SIDE OF DASH)
PNK/LT BLU WIRE
RED/LT GRN WIRE
RF, POWER RX, SIGNAL
SCP BUS (-) SCP BUS (+) GROUND PATS IND
STARTER RELAY
TAN/ORG WIRE
TX, SIGNAL GROUND BATTERY IGNITION
WHT/LT GRN WIRE
WHT/YEL WIRE
Go to component -> Passive anti-theft circuit, early production -> 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 STARTER RELAY
