Car Wiring Diagrams for Retractable running boards circuit for Ford Expedition IV facelift (2022-2024)

BATTERY JUNCTION BOX (BCMC) BLK WIRE BLK/BLU WIRE BLU/WHT WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT MODULE (DSM) (UNDER DRIVER'S SEAT) FUSE 30 GRN WIRE GRN/BLU WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE HALL EFFECT POWER HOT AT ALL TIMES INSTRUMENT PANEL CLUSTER (IPC) LEFT POWER RUNNING BOARD (PRB) MOTOR (UNDER LEFT SIDE OF VEHICLE) LEFT RB DEPLOY LEFT RB HALL EFFECT SIG LEFT RB STOW MEMORY SYSTEMS RIGHT POWER RUNNING BOARD (PRB) MOTOR (UNDER RIGHT SIDE OF VEHICLE) RIGHT RB DEPLOY RIGHT RB HALL EFFECT SIG RIGHT RB STOW SIG RTN VBATT VIO/GRY WIRE VIO/ORG WIRE VIO/RED WIRE WHT WIRE WHT/GRN WIRE YEL/VIO WIRE
