Cooling fan circuit for Ford Expedition IV facelift (2022-2024)

AMBIENT AIR TEMPERATURE (AAT) SENSOR BATTERY JUNCTION BOX (BCMC) BLK WIRE BLK/YEL WIRE BLU WIRE BLU/GRY WIRE BRN WIRE BRN/BLU WIRE CAC CHT COMPUTER DATA LINES SYSTEM COOLING FAN MOTOR 1 CYLINDER HEAD TEMPERATURE (CHT) SENSOR ENGINE CONTROLS SYSTEM ENGINE COOLING FAN RELAY #1 ENGINE COOLING FAN RELAY #3 FUSE 47 FUSE 49 FUSE 8 GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRY WIRE HOT AT ALL TIMES HOT W/ PCM POWER RELAY ENERGIZED HS CAN FD - ISP-R LIN AAT ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) SIG RTN VIO WIRE VIO/GRN WIRE WHT/GRN WIRE YEL WIRE YEL/ORG WIRE YEL/VIO WIRE

BATTERY JUNCTION BOX (BCMC) BLK WIRE BLU WIRE BRN WIRE CHARGE AIR COOLER (CAC) COOLING FAN MOTOR 1 CHARGE AIR COOLER (CAC) COOLING FAN MOTOR 2 CHARGE AIR COOLER (CAC) COOLING FAN RELAY COOLING FAN MOTOR 2 DEPLOY FUSE 147 FUSE 24 GRN WIRE GRN/BLU WIRE GRY WIRE HOT AT ALL TIMES HOT W/ RUN/ START RELAY ENERGIZED HOT W/ RUN/START RELAY ENERGIZED LEFT FRONT ACTIVE AIR DAM (AAD) ACTUATOR LIN LOWER ACTIVE GRILLE SHUTTER ORG/ WIRE RIGHT FRONT ACTIVE AIR DAM (AAD) ACTUATOR RIGHT SIDE OF RADIATOR) STOW UPPER ACTIVE GRILLE SHUTTER VIO WIRE VIO/GRN WIRE VPWR WHT WIRE WHT/GRN WIRE YEL WIRE YEL/ORG WIRE
