Ford Expedition IV facelift (2022-2024) sens power Wiring diagram
This page shows the only wiring diagram for the component.sens power, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram sens power (1 of 1)
BATTERY JUNCTION BOX (BCMC)
BLK/YEL WIRE
BLU/BRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DETENT
FUSE 202
FUSE 41
GRN/BLU WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
LEFT LIFTGATE DRIVE MOTOR ASSEMBLY (BASE OF LEFT "D" PILLAR)
LIFTGATE LATCH/UNLATCH ASSEMBLY
NCA WIRE
POSITION SENSOR
PRIMARY
PWR MTR-
RATCHET
RED WIRE
RELEASE MTR
RIGHT LIFTGATE DRIVE MOTOR ASSEMBLY (BASE OF RIGHT "D" PILLAR)
SECONDARY
SENS POWER
SENS RTN
SENS SIG 1
SENS SIG 2
VIO/BRN WIRE
VIO/RED WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/ORG WIRE
YEL/RED WIRE
YEL/VIO WIRE
ZERO POS
Go to component: -> Power liftgate circuit (2 of 3) -> SENS POWER
