Ford Expedition IV facelift (2022-2024) lin 04 vpwr Wiring diagram
This page shows the only wiring diagram for the component.lin 04 vpwr, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lin 04 vpwr (1 of 1)
AC OUTLET
AC-A
AC-B
BLK/BLU WIRE
BLK/VIO WIRE
BLU/BRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
DC/AC INVERTER MODULE
FROM BATTERY JUNCTION BOX (BCMC) (DIAGRAM 2 OF 8)
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 2 OF 8)
FROM BODY CONTROL MODULE (BCM) (DIAGRAM 5 OF 8)
FROM RCM POWER (FET) (DIAGRAM 7 OF 8)
GRN WIRE
GRN/BLU WIRE
GRN/RED WIRE
LED
LED GND
LIN 04
LIN 04 VPWR
MICRO -
NAVIGATION SYSTEM
ORG/GRN WIRE
ORG/WHT WIRE
STATUS
VBATT
VIO/WHT WIRE
WHT/GRN WIRE
WIRELESS ACCESSORY CHARGING MODULE
WIRELESS CHARGE SIGNAL OUTPUT (FET)
YEL/VIO WIRE
