Ford Expedition IV facelift (2022-2024) left panel discharge air temperature sensor Wiring diagrams

This page contains all the electrical diagrams for the component. left panel discharge air temperature sensor, in which he is found in the car Ford Expedition IV facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram left panel discharge air temperature sensor (1 of 2)

Wiring diagram left panel discharge air temperature sensor for Ford Expedition IV facelift (2022-2024)

Get access

BATTERY JUNCTION BOX (BCMC) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLOWER MOTOR BLOWER MOTOR CONTROL MODULE BLOWER MOTOR RELAY BLOWER RELAY BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM EVAP FEEDBACK FEEDBACK VARIABLE BLOWER CONTROL MOTOR + FUSE 13 GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE HAZARD HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE HOT AT ALL TIMES INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 1 LEFT FLOOR DISCHARGE AIR TEMPERATURE SENSOR LEFT PANEL DISCHARGE AIR TEMPERATURE SENSOR LEFT SIDE TEMPERATURE BLEND DOOR ACTUATOR LH FLR SENS 1 LH FRT SENS 1 MAX DEFROST INDICATOR MAX DEFROST REQUEST MOTOR MOTOR - (PINS: 29 TO 31 NOT USED) MS CAN + ORG/ WIRE REAR AIR DISTRIBUTION DOOR ACTUATOR REAR FLOOR AIR DISCHARGE TEMPERATURE SENSOR REAR TEMPERATURE DOOR ACTUATOR RH FLR SENS 1 RH FRT SENS 1 RIGHT SIDE TEMPERATURE BLEND DOOR ACTUATOR SIG RTN START/STOP DISABLE SW START/STOP IND START/STOP) TEMP 3 VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VREF (PINS: 4 TO 7 NOT USED) WHT WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Automatic a/c circuit, w/ 15 inch display (1 of 4) -> LEFT PANEL DISCHARGE AIR TEMPERATURE SENSOR

Wiring diagram left panel discharge air temperature sensor (2 of 2)

Wiring diagram left panel discharge air temperature sensor for Ford Expedition IV facelift (2022-2024)

Get access

BATTERY JUNCTION BOX (BCMC) BLK WIRE BLK/GRY WIRE BLK/VIO WIRE BLOWER MOTOR BLOWER MOTOR CONTROL MODULE BLOWER MOTOR RELAY BLOWER RELAY BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/ORG WIRE BLU/WHT WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM ENABLE/DISABLE SW IND EVAP FEEDBACK FEEDBACK VARIABLE BLOWER CONTROL MOTOR + FUSE 13 GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/ORG WIRE HAZARD HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE HOT AT ALL TIMES INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 1 LEFT FLOOR DISCHARGE AIR TEMPERATURE SENSOR LEFT PANEL DISCHARGE AIR TEMPERATURE SENSOR LEFT SIDE TEMPERATURE BLEND DOOR ACTUATOR LH FLR SENS 1 LH FRT SENS 1 MOTOR MS CAN + ORG/ WIRE REAR AIR DISTRIBUTION DOOR ACTUATOR REAR FLOOR AIR DISCHARGE TEMPERATURE SENSOR REAR TEMPERATURE DOOR ACTUATOR RH FLR SENS 1 RH FRT SENS 1 RIGHT SIDE TEMPERATURE BLEND DOOR ACTUATOR SIG RTN START/STOP DISABLE SW START/STOP IND START/STOP) TEMP 3 VBATT VIO WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/ORG WIRE VREF WHT WIRE WHT/BRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Automatic a/c circuit, w/o 15 inch display (1 of 4) -> LEFT PANEL DISCHARGE AIR TEMPERATURE SENSOR
