Ford Expedition IV facelift (2022-2024) left front radar pwr Wiring diagrams
This page contains all the electrical diagrams for the component. left front radar pwr, in which he is found in the car Ford Expedition IV facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front radar pwr (1 of 2)
BATTERY JUNCTION BOX (BCMC)
BLIS INDICATOR
BLK WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/BRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/RED WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (CCM)
DRIVER DOOR
DRIVER DOOR MODULE (DDM) (DRIVER DOOR)
ETHERNET
FRONT RADAR CAN -
FRONT RADAR GND
FRONT RADAR PWR
FUSE 137
FUSE 182
FUSE 183
GRN/BLU WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT AT ALL TIMES
HOT W/ ADAS MODULE RELAY ENERGIZED
IMAGE PROCESSING MODULE A (IPMA)
LEDS
LEFT EXTERIOR MIRROR
LEFT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
LEFT FRONT RADAR GND
LEFT FRONT RADAR PWR
LEFT FRONT SIDE OBSTACLE DETECTION CONTROL MODULE (SODCMC)
LEFT REAR RADAR GND
LEFT REAR RADAR PWR
LEFT REAR SIDE OBSTACLE DETECTION CONTROL MODULE (SODL)
MS CAN +
PASSENGER DOOR MODULE (PDM)
RADAR CAN -
RADAR GND
RADAR PWR
REAR RADAR CAN +
RIGHT EXTERIOR MIRROR
RIGHT EXTERIOR MIRROR BLIND SPOT (BLIS)/ CROSS TRAFFIC ALERT (CTA) LED
RIGHT FRONT RADAR GND
RIGHT FRONT RADAR PWR
RIGHT FRONT SIDE OBSTACLE DETECTION CONTROL MODULE (SODCMD)
RIGHT REAR RADAR GND
RIGHT REAR RADAR PWR
RIGHT REAR SIDE OBSTACLE DETECTION CONTROL MODULE (SODR)
VBATT
VIO/BRN WIRE
VIO/GRY WIRE
VIO/ORG WIRE
VIO/RED WIRE
VPWR
WHT/ORG WIRE
WHT/RED WIRE
WHT/VIO WIRE
YEL/BLU WIRE
YEL/GRN WIRE
YEL/ORG WIRE
YEL/VIO WIRE
Go to component -> Blind spot information system circuit -> LEFT FRONT RADAR PWR
Wiring diagram left front radar pwr (2 of 2)
BLIND SPOT INFORMATION SYSTEM CIRCUIT
BLU WIRE
BRN WIRE
BRN/GRN WIRE
BRN/WHT WIRE
COAX
FRONT CAMERA
FRONT RADAR CAN -
GRN/BLU WIRE
GRN/ORG WIRE
IMAGE PROCESSING MODULE A (IPMA)
LEFT FRONT ACTIVE PARK ASSIST SENSOR
LEFT FRONT INNER PARKING AID SENSOR
LEFT FRONT OUTER PARKING AID SENSOR
LEFT FRONT RADAR GND
LEFT FRONT RADAR PWR
LEFT SIDE CAMERA
REAR CAMERA
RIGHT FRONT INNER PARKING AID SENSOR
RIGHT FRONT OUTER PARKING AID SENSOR
RIGHT FRONT RADAR GND
RIGHT FRONT RADAR PWR
RIGHT SIDE CAMERA
SOLID STATE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/ORG WIRE
WHT/VIO WIRE
YEL/ORG WIRE
Go to component -> Parking assistant circuit (3 of 3) -> LEFT FRONT RADAR PWR
