Ford Expedition IV facelift (2022-2024) l spot on/off liftgate open/close Wiring diagram
This page shows the only wiring diagram for the component.l spot on/off liftgate open/close, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram l spot on/off liftgate open/close (1 of 1)
ANTI-LOCK BRAKE SYSTEM (ABS) MODULE
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BLU/RED WIRE
BLU/WHT WIRE
BODY CONTROL MODULE (BCM)
BRAKE FLUID SW
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR
ELECTRONIC PARK BRAKE SWITCH (IN CENTER CONSOLE)
FUSE 13
FUSE 19
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEADLAMP SWITCH
HOT AT ALL TIMES
HS CAN FD -
L SPOT ON/OFF
L SPOT ON/OFF LIFTGATE OPEN/CLOSE
LIN 9
MICRO -
MULTI- FUNCTION SWITCH
ORG/ WIRE
PASSENGER DOOR MODULE (PDM)
R SPOT ON/OFF
SIG RTN
STEERING COLUMN CONTROL MODULE (SCCM)
VBATT
VIO WIRE
VIO/GRN WIRE
VIO/GRY WIRE
WHT WIRE
WHT/BRN WIRE
WHT/ORG WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component: -> Chime circuit (1 of 3) -> L SPOT ON/OFF LIFTGATE OPEN/CLOSE
