Ford Expedition IV facelift (2022-2024) hill descent Wiring diagram
This page shows the only wiring diagram for the component.hill descent, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hill descent (1 of 1)
ACTIVE PARK ASSIST SWITCH
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU/RED WIRE
BODY CONTROL MODULE (BCM)
COMPUTER DATA LINES SYSTEM
ETHERNET
FUEL PUMP, SENDER UNIT
FUEL SENDER 1
FUEL SENDER 1 RTN
FUSE 13
FUSE 3
GLASS AJAR
GRN WIRE
GRN/BLU WIRE
GRN/VIO WIRE
GRY WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/VIO WIRE
HEAD-UP DISPLAY (HUD) MODULE
HILL DESCENT
HILL DESCENT/ TRAIL CONTROL
HOT AT ALL TIMES
INSTRUMENT PANEL CLUSTER (IPC)
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 2
LF DR AJAR
LIFTGATE
LOGIC GND
LOW WASHER
LOW WASHER FLUID WARNING INDICATOR SWITCH
LR DR AJAR
MICRO -
NCA WIRE
RF DR AJAR
RR DR AJAR
TCS ON/OFF
VBATT
VIO/GRY WIRE
VPWR
W/ PARKING AID
W/O PARKING AID
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/GRY WIRE
YEL/VIO WIRE
Go to component: -> Instrument cluster circuit (1 of 3) -> HILL DESCENT
