Ford Expedition IV facelift (2022-2024) fuel pump control module Wiring diagram
This page shows the only wiring diagram for the component.fuel pump control module, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram fuel pump control module (1 of 1)
12/22 SPEAKER
14 SPEAKER
28 SPEAKER
ALL TERRAIN CONTROL MODULE (ATCM)
AUDIO DIGITAL SIGNAL PROCESSING (DSP) MODULE)
BLK WIRE
BLK/BLU WIRE
BLK/VIO WIRE
BLUETOOTH ANTENNA 9
ELECTRONIC PARK BRAKE SWITCH
FRONT CONTROLS INTERFACE MODULE (FCIM)
FUEL PUMP CONTROL MODULE
FUEL PUMP CONTROL MODULE SHIELD
GLOVE COMPARTMENT LAMP
HEADREST FOLD/POWER LIFTGATE SWITCH
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
INSTRUMENT PANEL CONSOLE SWITCH ASSEMBLY 1
PASSIVE ANTI-THEFT SYSTEM (PATS) TRANSCEIVER
PRO TRAILER BACKUP ASSIST (PTBA) CONTROL KNOB
PUSH BUTTON START IGNITION SWITCH
REAR ENTERTAINMENT MODULE (RETM)
REAR HVAC MODULE
REAR SUNSHADE SWITCH
TRAILER BRAKE CONTROL SWITCH
USB CHARGE PORT
VEHICLE DYNAMICS CONTROL MODULE (VDM)
VIO WIRE
W/ 15 INCH DISPLAY
W/ COLUMN SHIFTER
W/ FLOOR SHIFTER
W/O 15 INCH DISPLAY
W/O SECOND ROW CONSOLE
WIRELESS ACCESSORY CHARGING MODULE
Go to component: -> Ground distribution circuit (5 of 10) -> FUEL PUMP CONTROL MODULE
