Ford Expedition IV facelift (2022-2024) front radar Wiring diagrams

This page contains all the electrical diagrams for the component. front radar, in which he is found in the car Ford Expedition IV facelift (2022-2024). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram front radar (1 of 2)

Wiring diagram front radar for Ford Expedition IV facelift (2022-2024)

Get access

ALL TERRAIN CONTROL MODULE (ATCM) ANTI-LOCK BRAKE SYSTEM (ABS) MODULE BLU WIRE BLU/GRN WIRE CAN (+) FRONT RADAR GEAR SHIFT MODULE (GSM) GRN WIRE GRN/BRN WIRE GRN/ORG WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE HS CAN FD - LEFT FRONT SIDE OBSTACLE DETECTION CONTROL MODULE (SODCMC) LEFT REAR SIDE OBSTACLE DETECTION CONTROL MODULE (SODL) OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM) ORG/ WIRE POWERTRAIN CONTROL MODULE (PCM) REAR RADAR RESTRAINTS CONTROL MODULE (RCM) STEERING COLUMN CONTROL MODULE (SCCM) VEHICLE DYNAMICS CONTROL MODULE (VDM) VIO/GRY WIRE W/ COLUMN SHIFTER W/O COLUMN SHIFTER WHT/ORG WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Computer data lines circuit (4 of 5) -> FRONT RADAR

Wiring diagram front radar (2 of 2)

Wiring diagram front radar for Ford Expedition IV facelift (2022-2024)

Get access

BRN/BLU WIRE CAN (+) CRUISE CONTROL MODULE (CCM) DRIVER STATUS MONITOR CAMERA MODULE (CMR) ETHERNET FRONT RADAR GATEWAY MODULE A (GWM) (LEFT "C" PILLAR) GRN WIRE GRN/BRN WIRE GRN/VIO WIRE GRY/BLU WIRE GRY/BRN WIRE HS CAN FD - IMAGE PROCESSING MODULE A (IPMA) POWER STEERING CONTROL MODULE (PSCM) REAR RADAR RIGHT END OF DASH) RIGHT FRONT SIDE OBSTACLE DETECTION CONTROL MODULE (SODCMD) RIGHT REAR SIDE OBSTACLE DETECTION CONTROL MODULE (SODR) TRANSFER CASE CONTROL MODULE (TCCM) VIO/GRY WIRE WHT/ORG WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Computer data lines circuit (5 of 5) -> FRONT RADAR
