Ford Expedition IV facelift (2022-2024) front passenger side redundant seat adjust switch Wiring diagram
This page shows the only wiring diagram for the component.front passenger side redundant seat adjust switch, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger side redundant seat adjust switch (1 of 1)
ADJUSTABLE PEDAL CONTROL MODULE
AUDIO FRONT CONTROL MODULE (ACM)
BLU/RED WIRE
FAMILY ENTERTAINMENT SYSTEM
FROM BATTERY JUNCTION BOX (BCMC) (DIAGRAM 1 OF 8)
FROM FUSE 15 (DIAGRAM 5 OF 8)
FRONT CONTROLS INTERFACE MODULE (FCIM)
FRONT PASSENGER SIDE REDUNDANT SEAT ADJUST SWITCH
FUSE 12
FUSE 13
FUSE 19
FUSE 24
FUSE 29
FUSE 32
FUSE 9
GATEWAY MODULE A (GWM)
GRN/RED WIRE
GRY/RED WIRE
HEADLAMP SWITCH
HEATING VENTILATION, AIR CONDITIONING (HVAC) CONTROL MODULE
INSTRUMENT PANEL CLUSTER (IPC)
INTRUSION/ INCLINATION SENSOR
KEYPAD SWITCH ASSEMBLY
LEFT FRONT SEAT CONTROL SWITCH
REAR ENTERTAINMENT MODULE (RETM)
REAR HVAC MODULE
RED WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE
RIGHT FRONT SEAT CONTROL SWITCH
ROOF OPENING PANEL MODULE
STEERING COLUMN CONTROL MODULE (SCCM)
TO AMBIENT LTG (FET) (DIAGRAM 7 OF 8)
TO FUSE 31 (DIAGRAM 2 OF 8)
VIO/RED WIRE
W/O SECOND ROW CONSOLE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Power distribution circuit (6 of 8) -> FRONT PASSENGER SIDE REDUNDANT SEAT ADJUST SWITCH
