Ford Expedition IV facelift (2022-2024) floor shifter Wiring diagram
This page shows the only wiring diagram for the component.floor shifter, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram floor shifter (1 of 1)
1 SPEED
2 SPEED
ALL TERRAIN CONTROL MODULE (ATCM)
BATTERY JUNCTION BOX (BCMC)
BLK/GRY WIRE
BLK/VIO WIRE
BODY CONTROL MODULE (BCM)
BRN/GRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CLUTCH
COMPUTER DATA LINES SYSTEM
FLOOR SHIFTER
FUSE 31
FUSE 64
FUSE 82
GRN/BLU WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/ORG WIRE
HI TO LOW
HOT AT ALL TIMES
HS CAN FD -
INSTRUMENT PANEL CLUSTER (IPC)
INTERNAL CASE GROUND
LOW TO HI
MTR-CCW
MTR-CW
NCA WIRE
POS 1
POS 1 MTR
POS 2
POS 2 MTR
POS 3
POS 4
POS 4 MTR POS 3 MTR
POS RTN
RIGHT END OF DASH)
TRANSFER CASE ASSEMBLY
TRANSFER CASE CLUTCH COIL
TRANSFER CASE CONTROL MODULE (TCCM)
TRANSFER CASE)
VBATT
VIO/GRN WIRE
VIO/RED WIRE
WHT/GRN WIRE
WHT/ORG WIRE
WHT/RED WIRE
YEL/RED WIRE
YEL/VIO WIRE
Go to component: -> 4wd circuit -> FLOOR SHIFTER
