Ford Expedition IV facelift (2022-2024) expedition w/ power rear windows one shot up/down Wiring diagram
This page shows the only wiring diagram for the component.expedition w/ power rear windows one shot up/down, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram expedition w/ power rear windows one shot up/down (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLUETOOTH ANTENNA 3
BRN/WHT WIRE
EXPEDITION W/ POWER REAR WINDOWS ONE SHOT UP/DOWN
EXPEDITION W/O POWER REAR WINDOWS ONE SHOT UP/DOWN
EXPEDITION W/O REAR HEATED SEATS
NCA WIRE
OCCUPANT CLASSIFICATION SYSTEM MODULE (OCSM)
PASSENGER DOOR MODULE (PDM)
PASSENGER SEAT BELT BUCKLE SWITCH
PASSENGER SEAT BELT TENSION SENSOR
PASSENGER SEAT POSITION SENSOR
PASSENGER SIDE FRONT REDUNDANT SEAT ADJUST SWITCH
REAR HEATED SEAT MODULE
RIGHT EXTERIOR MIRROR
RIGHT FRONT DOOR HANDLE INTERIOR AMBIENT LIGHTING LAMP
RIGHT FRONT DOOR TWEETER SPEAKER
RIGHT REAR DOOR HANDLE INTERIOR AMBIENT LIGHTING LAMP
RIGHT REAR DOOR LATCH
RIGHT REAR DOOR LOCK SWITCH
RIGHT REAR DOOR TWEETER SPEAKER
RIGHT REAR DOOR WINDOW CONTROL SWITCH
RIGHT SECOND ROW SEAT BACKREST HEATER MAT
RIGHT SECOND ROW SEAT BELT BUCKLE SWITCH
RIGHT SECOND ROW SEAT EASY FOLD MOTOR
RIGHT SECOND ROW SEAT RELEASE EASY ENTRY MOTOR
SECOND ROW CONSOLE AMBIENT LIGHT
SECOND ROW CUP HOLDER AMBIENT LIGHT
WHT WIRE
Go to component: -> Ground distribution circuit (9 of 10) -> EXPEDITION W/ POWER REAR WINDOWS ONE SHOT UP/DOWN
