Ford Expedition IV facelift (2022-2024) driver front seat cushion module Wiring diagram
This page shows the only wiring diagram for the component.driver front seat cushion module, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram driver front seat cushion module (1 of 1)
10-WAY
8 WAY
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLU WIRE
BLUETOOTH ANTENNA 2
DRIVER DOOR MODULE (DDM)
DRIVER FRONT SEAT AMBIENT LIGHTING LAMP
DRIVER FRONT SEAT BACKREST MODULE
DRIVER FRONT SEAT CUSHION MODULE
DRIVER MULTI-CONTOUR SEAT MODULE (SCMG)
DRIVER SCUFF PLATE LAMP
DRIVER SEAT BELT BUCKLE SWITCH
DRIVER SEAT MODULE (DSM)
EXPEDITION W/O REAR HEATED SEATS
FAMILY ENTERTAINMENT SYSTEM
FROM LEFT REAR DOOR WINDOW CONTROL SWITCH (DIAGRAM 7 OF 10)
GRY WIRE
LEFT EXTERIOR MIRROR
LEFT FRONT SEAT CONTROL SWITCH
LEFT MULTI-CONTOUR CONTROL PUMP
LEFT POWER RUNNING BOARD (PRB) MOTOR
LEFT SECOND ROW SEAT BACKREST HEATER MAT
LEFT SECOND ROW SEAT BELT BUCKLE SWITCH
LEFT SECOND ROW SEAT EASY FOLD MOTOR
LEFT SECOND ROW SEAT RELEASE EASY ENTRY SWITCH
LEFT THIRD ROW USB SMART CHARGER
NAVIGATOR LATE PRODUCTION
NCA WIRE
REMOTE FUNCTION ACTUATOR (RFA) MODULE
ROOF OPENING PANEL MODULE
TRAILER MODULE (TRM)
USED)
W/ MEMORY
W/O MEMORY
Go to component: -> Ground distribution circuit (6 of 10) -> DRIVER FRONT SEAT CUSHION MODULE
