Ford Expedition IV facelift (2022-2024) computer data lines system Wiring diagram

This page shows the only wiring diagram for the component.computer data lines system, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram computer data lines system (111 of 111)

Wiring diagram computer data lines system for Ford Expedition IV facelift (2022-2024)

Get access

ATFPC BLK WIRE BLU WIRE BLU/BRN WIRE BLU/GRN WIRE BLU/GRY WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE BRN/YEL WIRE CAN (+) COMPUTER DATA LINES SYSTEM GRN WIRE GRN/BLU WIRE GRN/BRN WIRE GRN/VIO WIRE GRN/WHT WIRE GRY WIRE GRY/BLU WIRE GRY/ORG WIRE GRY/VIO WIRE GRY/YEL WIRE LPC NCA WIRE SIG RTN SSA SSB SSC SSD SSE SSF SST-D TASV TCC TFT VIO WIRE VIO/GRN WIRE VIO/GRY WIRE WHT WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/ORG WIRE WHT/VIO WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/ORG WIRE YEL/VIO WIRE

Go to component: -> Wiring diagram engine performance 3.5l turbo (4 of 12) -> COMPUTER DATA LINES SYSTEM

Page 12 of 12
