Ford Expedition IV facelift (2022-2024) acc gap Wiring diagram
This page shows the only wiring diagram for the component.acc gap, which is found in the car Ford Expedition IV facelift (2022-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram acc gap (1 of 1)
A/D CHANNEL 1
A/D CHANNEL 2
A/D CHANNEL 3
A/D RETURN
ACC GAP
BLK/BLU WIRE
BLU WIRE
BRN/BLU WIRE
BRN/GRN WIRE
CANCEL/ RESUME
CLOCKSPRING
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL MODULE (CCM)
FRONT RADAR CAN -
FRONT RADAR GND
FRONT RADAR PWR
GRN WIRE
GRN/BRN WIRE
GRN/ORG WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HIGHWAY ASSIST
HS CAN FD -
ILLUM
IMAGE PROCESSING MODULE A (IPMA)
LEDS
LEFT LOWER STEERING WHEEL SWITCH (NAVIGATOR)
LEFT STEERING WHEEL SWITCH (EXPEDITION)
NCA WIRE
OUTPUT SHAFT SPEED (OSS) SENSOR
RES+
SET-
STEERING COLUMN CONTROL MODULE (SCCM)
TRANSMISSION ASSEMBLY
TRANSMISSION RANGE (TR) SENSOR
TRANSMISSIONS SYSTEM
TURBINE SHAFT SPEED (TSS) SENSOR
VBATT
WHT/VIO WIRE
YEL/GRY WIRE
YEL/ORG WIRE
Go to component -> Cruise control circuit (2 of 2) -> ACC GAP
